Model: FR-770/770V
Power: 120W
Sealing width: 6-10mm
Conveyor load: max 3kg
Option: horizontal or vertical
♦Instructions♦
1.FR- series automatic plastic film sealing machine adopts electronic constant
temperature control and automatic conveying device can control a variety of different shapes of plastic film tape, in a variety of packaging lines supporting the use of sealing length is unlimited.
2.The sealing machine can be equipped with wheels and embossing printing wheel, with the need to replace the fonts can be printed on the seal while the date of manufacture, shelf life, shelf life and other signs, sealing and marking legible and beautiful patterns.
3.Printing can be a complete seal, date, batch number with the need to replace, easy to use, in line with article Food Sanitation Law.
4.The automatic film sealing machine for pharmaceutical, pesticide, food, cosmetic,
lubricating oil and other industries foil bags, plastic bags, composite bags sealing, the sealing device has a solid, high efficiency; simple and compact structure, small size;
shape appearance, advanced technology, low power consumption; operation and easy maintenance, etc., is an ideal sealing machinery.
♦Parameter Date♦
Model | FR-770 |
Operation: | Electronic variable speed |
Temperature control: | Electronic thermostat control |
Printing method: | Stamps |
Voltage: | AC110/220V, 50/60Hz |
Power: | 120W |
Seal products speed : | 0-24m / min |
Seal products Thickness : | 0.02-0 .80 mm |
Seal width : | 6-15mm |
Sealing length: | unlimited |
Transporting loads: | <3kg |
Temperature range : | 0-400 °C |
Dimensions: | 810 × 370 × 320mm |
Weight: | 23kg |
*Note: The above parameters for reference only.
The machine constantly upgrades parameters may cause the actual discrepancies, please understand.
