Model: 500U 1000U 3000U 5000U
Filling range: 50-500/100-1000/500-3000/1000-5000ml
Filling speed: 5-15bottles/min
Accuracy: ±1%
Air pressure: 0.4-0.6MPa
Filling nozzle: 1 or 2
1.Be used for filling with particulate matter sauce, paste, liquid and other material;
2.Some of the materials use 304 stainless steel;
3.Pneumatic control, easy to operate, remove and clean; Ideal equipment for filling chilli sauce, peanut butter and so on.
Technical Parameters
| Filling Range | 50-500ml,100-1000ml,500-3000ml,1000-5000ml |
| Voltage | AC110/220V, 50/60Hz |
| Power | 120W |
| Air Pressure | 0.4-0.6MPa |
| Filling Speed | 8-25times/nozzle·min |
| Filling Accuracy | ±1% |
| Hopper Capacity | 80L |
| Net Weight | 100kg |
*Note: The above parameters for reference only.
The machine constantly upgrades parameters may cause the actual discrepancies, please understand.
