Filling range: 5-50ml
Accuracy: ±1%
Hopper capacity: 10L
Nozzle diameter: 4/8mm
Air pressure: 0.4-0.6MPa
Video link:
https://youtube.com/shorts/kPcdxW43ATM
Introduction:
The Small desktop pneumatic Filling Machine is specially designed by our factory for medium
or small size enterprises, laboratory, hospital or beasuty parlor in daily use chemical secton.
Its cofiguration is compact, acts agility and easy to use, all the parts which dip in the materiael
are made of stainless steel and polytetrafluorethylene.
Technical Parameters:
| Model | A02 |
| Material of Machine | Stainless steel 304 |
| Filling Range (ml) | 5-50 |
| Filling Speed(pcs/min) | 20-30 |
| Filling Accuracy | ±1% |
| Air Pressure(MPa) | 0.4-0.6 |
| Capacity of Hopper (kg) | 10 |
| Height Range (mm) | 0-200 |
| Bottle Diameter Range (mm) | 3-15 |
| Nozzles (pcs) | 2 (5mm/8mm) |
| Net Weight (kg) | 10 |
| Machine Size (mm) | 270x270x700 |
| Gross Weight(kg) | 12 |
| Package Size (mm) | 340×350×580 |
*Note: The above parameters for reference only.
The machine constantly upgrades parameters may cause the actual discrepancies, please understand.
