Filling range: 5-50ml
Accuracy: ±1%
Hopper capacity: 10L
Nozzle diameter: 4/8mm
Video link:
https://www.youtube.com/watch?v=WsvDsGiS2eg
https://www.youtube.com/shorts/_8CC2RJtwWc
Manual Liquid & Paste Filling Machine
Introduction:
YS-A03, manual injection principle, for 5-70ml quantitative filling;
Applicable to liquid paste shampoo cream lotion cosmetic and perfume;
Ideal machine for small production capacity.
Characteristics:
1)This machine has simple and reasonable structure, easy to use.
2)Adjusting screw of filling volume and filling speed can be controlled manually.
3)The part which contact the liquid/paste are made of SS304, clean and sanitary.
Technical Parameters:
| Model | A03 |
| Working Mode | Manual |
| Material of Machine | SS304 |
| Filling Range (ml) | 5-70 |
| Filling Speed | 20-30pcs/min(differs from man to man) |
| Filling Accurancy | ±1% |
| Capacity of Hopper (kg) | 10 |
| Nozzles (mm) | 5 or 8 |
| Bottle Diameter (mm) | 3-15 |
| Bottle Height (mm) | 0-200 |
| Net Weight (kg) | 10 |
| Machine Size (mm) | 270x270x700 |
| Gross Weight (kg) | 12 |
| Package Size (mm) | 340×350×580 |
*Note: The above parameters for reference only.
The machine constantly upgrades parameters may cause the actual discrepancies, please understand.
