Model: YTK-220
Bottle diameter: 15-120mm
Label height: 15-150mm
Label length: 25-300mm
Accuracy: ±1mm
Optional device: date printer, transparent label sensor
Product Description
1. A fully automated labeling machine, very accurate and fast.
2. Easy operation with the coding function to print expire date or batch number on the label.
3. Optional bottle organizer to improve usability and productivity and save more time.
4. Fully customizable according to your bottle's shape and size.
5. The transparent label is OK to use.
6. T6 aluminum alloy and SS304, GMP standard.
Technical Parameters
Model | YTK-220 |
Power | AC110V/220V, 50/60HZ, 1500W |
Drive Mode | Servo Motor |
Labeling Direction | Horizontal |
Labeling Speed | 0~200 pcs / min |
Labeling Accuracy | ±1mm (depends on bottle's shape) |
Bottle Diameter | 30~120mm |
Label Width | 15~150mm |
Label Length | 25~300mm |
Label Roll Outer Diameter | max 350mm |
Label Roll Inner Diameter | 75mm |
Weight | 200kg |
Size | 2000X950X1400mm |
Optional Function | date coding, transparent label sensor |
*Note: The above parameters for reference only.
The machine constantly upgrades parameters may cause the actual discrepancies, please understand.
